System Supported Linux，Android，Windows XP、7、8、10，MAC
Language Supported "English-United States; French-Canada; Dutch-Netherlands; Spanish-International; Latin American-Argentina; Portuguese-Brazil; Danish-Denmark; English-UK; Italian-Italy 142; French-France; German- Germany; Portuguese-Portugal; Finnish-Finland; Turkish-F; Japanese;
Russian-Russia; Northern Sami-Norway
[Support multi-country keyboard]"
Sensor Planar CMOS sensor 1280×800
X-6301B Technical ParameterModelX-6301B
ItemWireless 2D Barcode Scanner
Physical ParameterMaterialABS+PVC+PCPower SupplyCharge DC 5V ±5% ；Built-in 3.7V 2000mA lithium BatteryPower consumption0.45W（Working）; 0.23W（Standby）; 0.85W（Maximum）Weight151g±5g（Without wire）SizeL * W * H：186.0 * 72.2 * 99.8(unit:mm)Charging base sizeL * W * H: 220.0 * 91.2 * 71.0(unit:mm)【Optional】ColorBlack; grey whiteButton life＞100000Performance ParameterInterface2.4G；BluetoothSystem SupportedLinux，Android，Windows XP、7、8、10，MACLanguage SupportedEnglish-United States; French-Canada; Dutch-Netherlands; Spanish-International; Latin American-Argentina; Portuguese-Brazil; Danish-Denmark; English-UK; Italian-Italy 142; French-France; German- Germany; Portuguese-Portugal; Finnish-Finland; Turkish-F; Japanese;
Russian-Russia; Northern Sami-Norway
[Support multi-country keyboard]SensorPlanar CMOS sensor 1280×800Processor32-bit ARM MCU + BGAstorage512 KB (capacity can be customized)Light SourceRed light LED aiming + white light LED lightingMotion ToleranceCode128： 80cm/sec
QR： 85cm/secWireless transmission distance2.4G≤70m（Visual range）
Bluetooth≤10m（Visual range）Reading ModImageResolution≥4milBit error rate1/5000000Trigger ModeManual;Auto-Sensing;Continuous scanningPrompt ModeBuzzer + indicator lightRecognition angleTilt ±45°, deflection ±45°, rotation 360°Reading distance10mm-600mmPrint Contrast25%Charging timeappr.8hWorking Timeappr.40hScan speed100 times/secDecoding
Capability1D● Interleaved 2 of 5 ● Standard 2 of 5
● Matri 2 of 5 ● ITF-14
● Code39-Regular ● Code39-FullASCII
● Code93-Regular ● Code93-FullASCII
● Code128 ● Code11 ● UPCE0/E1
● EAN/GS1-128 ● Codabar ● MSI
● EAN/JAN-13 ● UPC-A ● JAN/EAN-8
● Plessey ● GS1 Databar ● Code 32 2D● Data Matrix ● QR Code ● PDF417 ● HanXin Code
● Aztec ● Micro QR ● Micro PDF417 ● Maxi codeScanning DepthQR 7.50mil 15byte：5cm - 10cm
QR 10.83mil 16byte：4cm - 16cm
Code39 5.83mil 15byte: 6cm - 16cmEnvironmental parametersIP GradeIP52Operating Temp.0 to 50℃ / 32 to 122℉Storage Temp.0 to 50℃ / 32 to 122℉Operating Humidity20% to 85%（No Condensation）Storage Humidity20% to 85%（No Condensation）ESD Protection15KV air dischargeShock ResistanceFree Fall 1.5m（concrete surface）Ambient light0→100000Lux
